Pan 360 Degree Tilt 180 Degree Rotation Borehole Camera
€ 5,700.00
Fast delivery within 72 Hours
Pan 360 Degree Tilt 180 Degree Rotation Borehole Camera
€ 5,500.00
Pan 360 Degree Tilt 180 Degree Rotation Borehole Camera/ Pan 360 Degree Tilt 180 Degree Rotation Borehole Camera
As an upgraded version of the Wellcamera, this system adds video recording and saving, depth counting display, and a well pulley. The entire system consists of a reel, camera head, and data control unit. The data control unit integrates a 12-inch LCD monitor and a USB 2.0 data acquisition card, allowing users to view, save, and comment on photos/videos on a customer-supplied laptop. The system has a built-in 12V battery and can also connect to an external 12V battery.
Camera head operating conditions: Maximum pressure 35 bar (350 meters of water column), temperature range -10°C to +50°C.
| Place of Origin | China |
|---|
Details About Pan 360 Degree Tilt 180 Degree Rotation Borehole Camera
Key Technology and Performance
Design and User Experience
| CAMERA HEAD | |
| Diameter | 73mm/50mm/40mm |
| Length | 150mm |
| Sensor type | colour CCD 1/3” |
| Resolution | 700 lines |
| Minimum light intensity required | 0.005 lux @ F 1.2 |
| Lens | 2.9mm fixed lens – wide angle 120° |
| Light type | 16x high-intensity LED (max. 400 lumen) |
| Waterproof protection | IP68, water column of 350m (35 bar) |
| MONITOR | |
| Display dimensions and type | 12‘ TFT LCD |
| Image aspect ratio | 16:9 o 4:3 |
| Resolution | 800×480 pixel |
| System | NTSC/PAL |
Application:
Specification
Overview
Customer Reviews
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address
2-3 Days
From $20
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
From $40
-
Warranty 1 year
-
Free 30-Day returns
Specification
Overview
Processor
Display
RAM
Storage
Video Card
Connectivity
Features
Battery
General
Description
Fast delivery within 72 Hours
Pan 360 Degree Tilt 180 Degree Rotation Borehole Camera
€ 5,500.00
Pan 360 Degree Tilt 180 Degree Rotation Borehole Camera/ Pan 360 Degree Tilt 180 Degree Rotation Borehole Camera
As an upgraded version of the Wellcamera, this system adds video recording and saving, depth counting display, and a well pulley. The entire system consists of a reel, camera head, and data control unit. The data control unit integrates a 12-inch LCD monitor and a USB 2.0 data acquisition card, allowing users to view, save, and comment on photos/videos on a customer-supplied laptop. The system has a built-in 12V battery and can also connect to an external 12V battery.
Camera head operating conditions: Maximum pressure 35 bar (350 meters of water column), temperature range -10°C to +50°C.
| Place of Origin | China |
|---|
Details About Pan 360 Degree Tilt 180 Degree Rotation Borehole Camera
Key Technology and Performance
Design and User Experience
| CAMERA HEAD | |
| Diameter | 73mm/50mm/40mm |
| Length | 150mm |
| Sensor type | colour CCD 1/3” |
| Resolution | 700 lines |
| Minimum light intensity required | 0.005 lux @ F 1.2 |
| Lens | 2.9mm fixed lens – wide angle 120° |
| Light type | 16x high-intensity LED (max. 400 lumen) |
| Waterproof protection | IP68, water column of 350m (35 bar) |
| MONITOR | |
| Display dimensions and type | 12‘ TFT LCD |
| Image aspect ratio | 16:9 o 4:3 |
| Resolution | 800×480 pixel |
| System | NTSC/PAL |
Application:
